A compound microscope uses two sets of lenses in a row. The objective, close to the sample, forms a magnified image, and the eyepiece magnifies that image again. That two-stage design is what lets a school microscope show individual cells, and it is also why the knobs and dials feel like a lot on day one.

Below, every part of a standard student or lab compound microscope is labeled in one table. Then come the magnification arithmetic, a focusing method that keeps lenses and slides intact, a five-minute wet mount, and plain advice on microscopes for kids.

Microscope parts labeled

Read the table top to bottom, roughly the order you meet the parts when you look down the instrument.

An easy way to hold all of that in your head is to sort the parts into three systems. The optical system (eyepiece, objectives, condenser) makes the image. The mechanical system (arm, stage, nosepiece, focus knobs) holds and moves things. The illumination system (illuminator, condenser, diaphragm, brightness control) controls the light. When the picture looks wrong, ask which system is at fault.

Reading the numbers on an objective

Each objective is engraved. The large number is magnification, such as 40x. Next to it is the numerical aperture, for example 0.65, which describes how much light the lens collects and sets how fine a detail it can resolve. Many objectives also show the tube length the lens was designed for (160 or an infinity symbol) and the coverslip thickness it expects in millimeters, usually 0.17. A 100x objective is usually marked "oil", meaning it only works with a drop of immersion oil between lens and slide.

Total magnification, and what it does not tell you

Total magnification is the eyepiece power times the objective power.

More magnification is not the same as more detail. An ordinary light microscope cannot separate two points much closer than about 0.2 micrometers, a limit set by the wavelength of visible light. Microscope makers use a rule of thumb that useful magnification tops out at around 1,000 times the numerical aperture of the objective. Past that you get "empty magnification": a bigger, blurrier picture with nothing new in it. Remember that when a toy box promises 2000x.

What you need

• A compound microscope with a working light
• Prepared slides, or blank slides and coverslips for your own mounts
• Lens paper and lens cleaner (never tissues or a sleeve)
• Immersion oil, only if you will use the 100x objective
• For the wet mount: an onion, tweezers, a dropper, water and iodine stain

How to use a compound microscope

1. Carry it with two hands: one on the arm, one under the base, held upright. Set it down a few inches from the edge of the bench.
2. Start low. Switch on, set the brightness to medium and turn the nosepiece until the 4x objective clicks into place.
3. Place the slide coverslip side up, held by the clips or the mechanical stage, with the sample over the aperture.
4. Close the gap while watching from the side. Use the coarse knob to bring the 4x objective and the slide close together, with your eyes on the gap, not in the eyepiece. This is how you avoid driving a lens into a slide.
5. Focus by opening the gap. Now look through the eyepiece and turn the coarse knob slowly so the gap widens until the sample appears. Sharpen it with the fine knob.
6. Set the eyepieces. On a binocular head, slide them together or apart until you see one circle. Focus with the fine knob using the eye without a diopter ring, then close that eye and turn only the diopter ring for the other.
7. Center, then switch up. Most student microscopes are parfocal, meaning the image stays nearly in focus when you change objectives. Move the feature to the center of the field, rotate to 10x, and refocus with the fine knob.
8. Go to 40x and use the fine knob only. This objective sits very close to the slide, so coarse focus is off limits from here on.
9. Adjust the light. Higher power needs more light, so open the diaphragm or raise the brightness. For unstained cells, closing the diaphragm partway adds contrast.
10. For 1000x, add oil. Focus at 40x, swing the nosepiece halfway, put one drop of immersion oil on the slide, then rotate the 100x objective into the drop and use the fine knob. Don't swing the 40x back through the oil.
11. Finish properly. Lower the stage, return to 4x, remove the slide, wipe oil off the 100x objective with lens paper, switch off and cover the microscope.

Why does oil help? Immersion oil has about the same refractive index as glass, roughly 1.5, so light leaving the slide does not bend away at an air gap and miss the lens. More light collected means a higher numerical aperture and finer detail.

Common mistakes

• Starting at high power. You see blur or a blank glow. Always find the sample at 4x first.
• Using coarse focus at 40x or 100x. This is how slides crack and front lenses get scratched.
• Too much light. A washed-out field hides unstained cells. Close the diaphragm before you blame the sample.
• Cleaning lenses with tissue. Paper fibers and grit scratch lens coatings; use lens paper.
• Leaving oil on the lens, or getting it on the 40x. Dried oil clouds the 100x objective, and oil on a dry objective ruins its image until it is cleaned off.
• Thick samples. Light has to pass through the specimen. If it is opaque, slice it thinner or use a stereo microscope.
• Squeezing one eye shut on a monocular microscope. Keep both eyes open and ignore the second view; it is much less tiring.

Worked example: an onion skin wet mount and a size check

Onion epidermis is a classic first sample. It is one cell thick, needs nothing special, and shows cell walls and nuclei clearly once stained.

1. Cut a piece of onion and snap one of the fleshy layers. With tweezers, peel the thin, transparent skin from the inner surface.
2. Put a drop of water, or iodine solution to stain the nuclei, in the middle of a clean slide and lay the skin flat in it.
3. Lower a coverslip at an angle: touch one edge to the drop, then let it fall slowly. This pushes the air out ahead of it, so you get fewer bubbles.
4. Blot extra liquid at the edge with a paper towel, then view at 4x, 10x and 40x.

Now estimate the size of a cell. Many eyepieces are engraved with a field number, often 18 to 22. Divide it by the objective's magnification and you get the diameter, in millimeters, of the circle you see. With a field number of 18:

• At 4x, the field is 18 / 4 = 4.5 mm across.
• At 10x, it is 1.8 mm.
• At 40x, it is 0.45 mm, or 450 micrometers.

Suppose about 7 onion cells laid end to end span the field at 10x. Each cell is then about 1.8 / 7 = 0.26 mm, or 260 micrometers, long. Onion skin cells are commonly described as about a quarter of a millimeter long or a little more, so a result in that region means the method worked. To check, switch to 40x: one cell should now cover a bit more than half the field's width (260 of 450 micrometers). If your numbers are far off, check the field number on your eyepiece and whether you counted along the long axis.

Counting within a known area is also how a hemocytometer works: a grid of known size under the microscope turns a cell count into cells per milliliter, the sum our hemocytometer calculator does for you.

Choosing a microscope for kids

A child's first microscope does not need 1000x. For younger children, a stereo (dissecting) microscope at about 10x to 40x is often more rewarding than a compound one. It shows solid objects in 3D, so leaves, insects, coins, salt crystals and fabric all work with no slide preparation. A compound microscope makes more sense once a child wants to look at cells, pond water and prepared slides, which for many is somewhere in the upper elementary or middle school years.

Whichever type, the features that make a difference are glass lenses rather than plastic, a metal frame and focus mechanism, an LED light, a fine focus knob on compound models, and modest magnification claims. Kits that bundle blank slides, a few prepared slides, a dropper and stains make the first sessions easy. Supervise stains and anything glass, and teach the "watch from the side" rule from step 4 on the very first day.

Those habits carry straight into lab jobs. If you are helping a student think about biology as a career, our page on careers in the life sciences shows where bench skills lead, and the guide to how to use a micropipette is the natural next skill to learn.

Bench essentials

• Student compound microscope with prepared slides40x to 1000x · LED light · 25 prepared slides includedA monocular teaching microscope covering 40x to 1000x, enough for stained cells and tissue sections.Open on Amazon
• Prepared slide set, 48 specimens48 slides · plants, animals, insectsReady-made slides of plant, animal and insect tissue for practising focus and identification.Open on Amazon
• Blank slides with cover slips50 slides · 100 cover slips · ground edgesPre-cleaned glass slides and square cover slips for making your own wet mounts.Open on Amazon
• Dual LED microscope kit for childrenages 8 to 12 · top and bottom LEDA sturdy starter microscope with lights above and below, so children can look at both slides and solid objects.Open on Amazon

Picked from specifications, manuals and published reviews; we have not tested these items ourselves. All our bench picks

FAQ

What are the main parts of a compound microscope?

The eyepiece, objective lenses on a revolving nosepiece, a stage with clips or a mechanical stage, a condenser with an iris diaphragm, the illuminator, coarse and fine focus knobs, the arm and the base. The labeled table at the top explains each one.

What is the difference between a compound and a stereo microscope?

A compound microscope looks through thin, transparent samples at about 40x to 1000x. A stereo microscope uses two separate light paths to give a 3D view of solid objects at lower power, usually 10x to 40x or so.

Why does the image move the wrong way?

The objective forms an inverted image and the eyepiece does not flip it back, so the view is rotated. Moving the slide left moves the image right, and up moves it down.

Do I need immersion oil?

Only for the 100x objective, which is designed for it. The 4x, 10x and 40x objectives are dry lenses and should never touch oil.
